General
|
||
|
Frequency Range
|
65MHz-108MHz(Only commercial FM radio reception)
VHF:136MHz-174MHz(Rx/Tx) UHF:400MHz-520MHz(Rx/Tx) |
|
|
Memory Channel
|
Up to 128 Channels
|
|
|
Frequency Step
|
2.5KHz/5KHz/6.25KHz/10KHz/12.5KHz/20KHz/25KHz
|
|
|
Operated Voltage
|
DC 7.4V
|
|
|
Battery capacity
|
2800MAh Li-ion
|
|
|
Duty cycle
|
03/03/54min.(Rx/Tx/Standby)
|
|
|
Frequency Stability
|
±2.5ppm
|
|
|
Operated Temperature
|
-20°C to +55°C
|
|
|
Antenna Impedance
|
50Ω
|
|
|
Dimensions (L×W×H)
|
58×32×130mm (not including antenna)
|
|
|
Weight
|
130g (not including battery & antenna)
|
|
|
Consumption in standby
|
380mA
|
|
|
Communication Range
|
about 5-8km
|
|
|
Receiver
|
Wide band
|
Narrow band
|
|
Sensitivity (12dB SINAD)
|
≤0.20 uV
|
≤0.20 uV
|
|
Intermodulation
|
≥60dB
|
≥60dB
|
|
Spurious Response
|
≥65dB
|
≥65dB
|
|
Maximum deviation
|
≤±5kHz
|
≤±2.5kHz
|
|
Audio Power Output
|
1W
|
1W
|
|
Transmitter
|
Wide band
|
Narrow band
|
|
RF Power Output
|
8/ 5W/1W(Max 5W)
|
|
|
Type of modulation
|
FM
|
|
|
Maximum deviation
|
≤±5KHz
|
≤±2.5KHz
|
|
Emission class
|
16kΦF3E
|
11kΦF3E
|
|
Spurious Emission
|
<-60dB
|
<-60dB
|
